Standard

Premium Finish Face Mix Technology

The original paving stone shape offers contemporary elegance for commercial and residential projects.

Standard

Image shown: Strandard – Northern Shadow | Photo courtesy of Blue Pine Enterprises

RECOMMENDED APPLICATIONS

Patios
Patios
Walkways
Walkways
Residential Driveway Parking
Residential Driveway/Parking
Specification Sheet
Download Specsheet

COLOURS:

Colours in photographs are not exact representations, but are given to provide close reference. Measurements and product dimension are nominal.

Standard Natural
Natural
Standard Charcoal
Charcoal
Standard Northern Shadow
Northern Shadow
Standard Somerset
Somerset

SPECIFICATIONS:

H-20/HS-20

All our pavers meet the H-20/H-S20 loading requirements. This determination allows for an occasional heavy vehicle such as a fire truck driving on the pavers. Specific site requirements will determine the appropriate paver usage. For example, heavily trafficked areas require more robust pavers installed in specific laying patterns.

For more information on H-20/HS-20 Loading, please click here:

Individual Sizes:

Standard Individual Size
Size (in) Pieces per sq.ft. Sq.ft. per Pallet Shipping Weight PCS / Pallet
Half Standard
4-7/16″ x 4-7/16″ x 2-3/8″ 112.5mm x 112.5mm x 60mm		 7.2 98 1225kg / 2700lbs 720
Standard
8-7/8″ x 4-7/16″ x 2-3/8″225mm x 112.5mm x 60mm		 3.6 98 1225kg / 2700lbs 360
Double Standard
8-7/8″ x 8-7/8″ x 2-3/8″225mm x 225mm x 60mm		 1.8 98 1225kg / 2700lbs 180

All sizes including 3 mm Spacer Bars

INSTALLATION PATTERNS:

1/2 Offset Runner Bond P100
Sizes % of Area Area
4.5 x 9 100 27 sqft
Parquet Pattern P101
Sizes % of Area Area
4.5 x 9 100 27 sqft
90° Herringbone P102
Sizes % of Area Area
4.5 x 9 94 25.76 sqft
4.5 x 4.5 6 1.68 sqft
Pin Wheel Pattern P103
Sizes % of Area Area
9 x 9 80 39 sqft
4.5 x 4.5 20 9.75 sqft
Modified Ashlar Pattern P104
Sizes % of Area Area
9 x 9 45 12.38 sqft
4.5 x 9 45 12.66 sqft
4.5 x 4.5 10 2.67 sqft
1/2 Offset Runner Bond with 1/2 Standard Insert P106
Sizes % of Area Area
4.5 x 9 67 19.32 sqft
4.5 x 4.5 33 9.38 sqft
1/2 Offset Runner with Double 1/2 Standard P107
Sizes % of Area Area
9 x 9 67 15.68 sqft
4.5 x 4.5 33 8.68 sqft
Modified Lattice Pattern P108
Sizes % of Area Area
4.5 x 9 75 26.88 sqft
9 x 9 25 8.96 sqft
Layered 1/2 Offset Runner Bond P109
Sizes % of Area Area
4.5 x 4.5 44 11.34 sqft
9 x 9 56 14.56 sqft
1/2 Standard and Double Standard Checkerboard P110
Sizes % of Area Area
4.5 x 4.5 50 14 sqft
9 x 9 50 14 sqft
Standard Ashlar Pattern P111
Sizes % of Area Area
9 x 9 50 7.2 sqft
4.5 x 9 25 3.2 sqft
4.5 x 4.5 25 3.3 sqft
